MY series touch-all computer using metal profile edge graphic design, stylish and beautiful, equipped with high-definition display monitoring panel combined with a wealth of computer configuration, smooth corner design, user-friendly safety care, high-strength body with multi-point smooth capacitive touch panel, waterproof light, high wear, stable performance with a variety of installation methods, stylish, beautiful.
✦ Controller:
12.1 inch-PC：
18.5 inch-PC：
19 inch-PC：
21.5 inch-PC：
✦ Features:
Pure flat without hindrance more smooth, metal profile stoush reinforcement body, line beauty, smooth touch panel, equipped with high-definition video monitoring screen perfect presentation screen texture, so that the picture information more delicate and rich configuration scheme, professional POS consumption, back kitchen, building security, information advertising to create.
* 12.1” LED-backlit panel with long life
* Wide operating temperature -20°C~70°C
* General brightness 350 cd/m2
* True Plane - Fashion Style
* Wide-view view
* Ultra-narrow ultra-thin profile - metal housing, injection molding
| System configuration | |
|---|---|
| Motherboard | RK32 |
| CPU Model | Quad-core Cortex-A17 up to 1.8GHz |
| GPU | Mali-T764 GPU |
| RAM | LPDDR-III 2GB（4GB optional） |
| Store | 16GB EMMC NAND Chip Max 64G |
| Multimedia | 4K UHD H265/H264 |
| WiFi | IEEE 802.11 b/g/n |
| Bluetooth | BT.2020/BT.709 |
| Amplifier output | 8 Ohm 10W Dual Audio Amplifier |
| System | Android 5.0/7.0/8.0 |
| Feature items | Specification |
|---|---|
| Model | MY126(RK32) |
| Size | 12.1 inch |
| Overall Dimension | |
| Packing Size | 410*350*185mm |
| Resolution | 1024 x 768 |
| Color | 16.7M |
| Contrast | 800:1 |
| Brightness | 350 cd/m² |
| Response time | 16ms |
| Light Life LED | 30K/H |
| Perspective | 80/80/80/80 |
| Gross/Net Weight | 5Kg/3.5Kg |
| Cover Glass Thickness | 1.8mm |
| Light Transmission | ≥90% |
| Surface Strength | 3H |
| Touch Life | ≥1000 times |
| Operating Humidity | 20%-80% RH |
| Operating Temperature | -20°C~70°C |
| Storage Temperature | -30°C~80°C |
| Power Consumption | 14W |
| Power Input | 12V DC ±5% 5.5x2.5mm |
| Installation Method | VESE、Desktop |
| Signal Ports | VGA x 1、HDMI x 1、USB2.0 x 3、USB3.0 x 1、LAN(RJ45) x 1、Audio x 1、Mic x 1、12V DC-in x 1 |
